| P10 HD LED Electronic Full Color Events Display Screen | |||
| Technical Specifications | |||
| No. | Item | Specifications | |
| 1 | Pixel Pitch | 10mm | |
| 2 | Pixel Configuration | 1R1PG1B | |
| 3 | Module Size | 160mm x 160mm | |
| 4 | Cabinet Size(WxH) | 960mm x 960mm | |
| 5 | Cabinet Frame Structure Material | Die-casting aluminum | |
| 6 | Cabinet Weight | 40Kg | |
| 7 | Screen Resolution | 10,000 dots/㎡ | |
| 8 | Screen Brightness | 7000 nits | |
| 9 | Brightness Adjustment | manually or automatically | |
| 10 | Driving Method | constant current 1/4 | |
| 11 | View Angle | Horizontal 110° Vertical 60° | |
| 12 | Optimum Viewing Distance | 5m to 250m | |
| Our LED Display Screen Features | |||
| 1. Convenient to install and disassemble Our cabinets feature simple designs, making them easy-to-install and disassemble. The cabinets include interlocks, as well as external signal and power sockets. 2.Automatic backup system Our LED Displays could utilize two computers to ensure interruption-free display of images and videos. For instance, if one unit was to shutdown due to technical issues, the other unit acts as a back-up solution automatically. 3. All-weather designs With an IP 65 rating, our cabinets offer ventilation and protection from rain or water damage. 4. High refresh rates With high refresh rates, our products can display flicker-free video images – including live video feeds. 5. Stability a.) Connectors for power cables ensure stability of the power supply and voltage. b.) Our Swiss-made cable connectors guarantee perfect signal communication. 6. The kingpins and side lockers Our cabinet kingpins and side lockers ensure that our displays are hung safely and seamlessly. They can be used to adjust the gap between adjacent cabinets according to your requirements and applications. |
|||
P10 HD LED Electronic Full Color Events Display Screen
